1. 석유화학제품의 주요 공정인 반응기에 설치
2. 반응기 내부의 석유화학 제품을 이송, 샘플체취 하는 목적
3. 기체를 완벽하게 차단하는 기술 집약적 밸브
4. 1500LB 이상의 고압에서도 완벽한 Sealing이 보장됨
1. Installed in the reactor in the main petrochemical process.
2. Transport of petrochemical product inside the reactor to obtain sample.
3. Technology-intensive valve with completely sealing the gas
4. Perfect sealing at high pressure more than ANSI 1500LB
- Seat Type
1. Metal to metal Seat
2. PTFE Seat
3. O-ring Seat
4. Packing Seat
- Flange Dimensions
ANSI B 16.5
- Pressure Rating
150psi, 300psi, 600psi, 900psi, 1500psi
NC controlled horizantal bandsaws with linear guideways are ideal for mitre cuts with different quantities. With movement of bow it’s possible to cut between 90° and +30°. You can do 10 different programming (lenght and quantity) and can be watched on digital panel. Measurement is done by repeating the stroke accouring to 500 length stroke Cutting capacity at 90° is 540mm x 670mm for flat type and 540 mm for round shaped materials. With auto height adjustment sensors bow approachs the material with fast speed and hydraulic cutting control allows the bow go up over the material after the cut. All this process is controlled mechanical switch. Fixing the bow at any angle is controlled by hydraulical brake system and you can control it by another digital counter placed on main body of machine. As in all Bekamak products in BMSO 540CGH, safety is most important priority and all mechanical and electrical devices are set for best safety mesaures.
* 절단 능력(mm) : Round 430 Square 430
* Motor Output : Saw Blade 10HP(7.5kw) Hydraulic : 3 HP(2.25kw)
* Saw blade : 6050*54*1.6 mm
* Chip conveyor 포함
* Nesting fixture (상단 바이스), Pressure Regulator ( 압력 조절장치) 포함
